This video goes over range estimation with FMCW radar and gives a little insight into why you might want to use it over a traditional pulsed radar. There are many more trade-offs between the two that I don't discuss here, but this should give you a basic understanding of the technology. I'll use this as a basis for future videos on FMCW radar. There is a ton to cover and I'm excited to dive into those animations and explanations! Who is this for? Well, anyone interested in radar, but I did make a few assumptions about the viewer's background including a basic understanding of math and knowledge of what an electromagnetic wave is. Some of the many resources I used when learning about this: - Jon Kraft's series on FMCW radar hardware and software (Analog Devices) ( @jonkraft/videos) - Small and short range radar systems (book) ( ) - The phaser FMCW radar platform ( ) - Radar Basics: How to Build a 24 GHz FMCW Radar System - Alex Andrews (Analog Devices) ( ) - Frequency-Modulated Continuous-Wave Radar (FMCW Radar) - ( %20Modulated%20Continuous%20Wave% ) Some of the caveats to the information presented in this video: - Pulsed radars often transmit more complex waveforms than a simple sine wave (e.g., pulse compression) - FMCW radars often also have some "off" time between chirps - FMCW radars will many times transmit a series of chirps then combine them in post-processing into a coherent processing interval (CPI) - See the next video on velocity estimation :) - Not all power is reflected from the target but it is instead scattered in many directions --------------------------------------------------- - Channel Memberships: - Merch: - Website: -------------------------------------------------- All animations shown were created using Manim Community ( ) - a Python animation library written by 3Blue1Brown ( @3blue1brown) and maintained by the community. Huge thanks to everyone working on this incredible project! Code for the animations can be found on my GitHub: Errata: - I probably should have labeled the time shift from transmission to reception as t_{shift} and not t_{0} for clarity and parity with the upcoming video on the hardware implementation. - "Keyring" should be "keying" #somepi #manim
