Serial Wombat Chips are available at This video shows how I'm helping Steve in British Colombia configure two Serial Wombat 8B chips in his Arduino project. Steve is working with Challenged Sailors San Diego to build adaptive equipment to allow people living with disabilities to sail a sail boat. This video shows how to use the Wombat Panel application to automatically generate configuration code, and how to load different pin mode images into the SW8B. 0:00-2:02 Project Overview 2:03-2:58 Project Serial Wombat Requirements 2:59-3:24 Jon's Hardware Test Platform 3:25-4:30 Address Solder Jumper and Pins 4:31-5:11 Checking for chips with SerialWombatChipFinder example 5:12-5:53 Seeing which pin modes are supported by firmware 5:54-7:55 Picking and downloading a new firmware image 7:56-14:45 Auto generation of Configuration code 14:46-16:08 Adding code to reset PWM timeouts 16:09-17:03 Configuration Error Handler Demo 17:04-18:30 Conclusion
