An Open Source Motorized XYZ Micro-Manipulator - Affordable sub µm Motion Control

A low-cost and easy to build 3-Axis motion plattform is presented. It can achieve step sizes down to 50nm while supporting arbitrary acceleration limited motion paths in a working volume of 23x23x23mm³. The simple G-Coder interface allows easy control from printer-hosts or custom software. The device can be used in applications, like automated microscopy, optical alignment or maskless lithography. ✅ Project on Github: 🠲 I am looking for a better project name? Any ideas are welcome. *** Video Chapters *** 00:00 Intro 01:18 Overview 01:52 Miniature Ball Joints 03:41 Stepper Motors 04:53 Magnetic Encoders 08:18 Electronics 10:25 Firmware 13:11 Kinematic Model 14:33 Build & Assembly 19:05 Results & Applications 24:25 Whats Next ?
