Creating AFM resonant probes using shattered silicon.

Resonant probes for atomic force microscopy (AFM) can be created using shattered silicon wafers. We describe how to create silicon shards and then attach them to a quartz tuning fork for use in an AFM. The original method was described by F.J. Giessibl et. al. Copyright Mad City Labs, Inc. 2019. Keywords: atomic force microscope, AFM, SPM, tuning fork AFM, scanning probe microscope, phase lock loop controller, nanopositioning, nanopostiioner, Silicon tip, resonant probe, silicon, tuning fork, Si(111)
