It's the month for Raspberry Pi reverse engineering, apparently! First I showed the Pi Zero 2W in a Pico form factor: And now @TubeTime has reverse-engineered the Compute Module 5! I've decided to run through all the scans I recently did with Lumafield, for the benefit of anyone reverse engineering any of the other Pi models, and here they are, in all their glory! - Raspberry Pi 4 model B: - Raspberry Pi CM4: - Raspberry Pi Zero 2 W: - Raspberry Pi 5: - Raspberry Pi CM5: HUGE thanks to Lumafield for helping me produce these scans. Support me on Patreon: Sponsor me on GitHub: Merch: 2nd Channel: @GeerlingEngineering 3rd Channel: @Level2Jeff Contents: 00:00 - TubeTime wet-sands the CM5 02:10 - CM5 walkthrough (ft solder balls) 04:55 - Pi 5 walkthrough (ft magnetics) 08:05 - CM4 walkthrough (ft memory layouts) 09:04 - Pi 4 walkthrough (ft solder voids) 10:18 - Thanks to TubeTime and Lumafield
