Double Capacitor Single Phase Motor Connection ||Centrifugal Switch Connection #capacitor #connection #singlephase Your queries : Capacitor Start Capacitor Run Motor single phase double capacitor motor connection single phase motor double capacitor motor capacitor start motor permanent capacitor motor capacitor start induction motor double capacitor motor connection two capacitor motor start/run capacitor wiring diagram single phase motor wiring diagram with capacitor wiring single phase motor Rewinding single phase motor repairing electrical motor repairing work motor repairing electrical engineering motor connection work connection in hindi double capacitor single phase motor single phase capacitor start motor capacitor running starting Single phase motor wiring diagram with capacitor start and capacitor run In This Video we will Learn how to connection of single phase motor with two Capacitors in very easy and simple way Q. why capacitor is used in single phase motor ? Ans. Single phase motors are not a self-starting motor, single phase power supply cannot create rotating magnetic field because of its nature (only one phase). So that to rotate the single phase motor we have to give rotary moment or manual rotation to get continuous rotation. But at that same time we can run the motor but adding extra starting winding and the winding will be connected in series with the capacitor. Technically it is called split phase capacitor method. Q. Why do motors have two capacitors? Ans. Single-phase induction motors that have two capacitors have a higher torque capability when starting and accelerating. The starting capacitor is larger and thus allows a higher current in the starting winding and a greater phase shift of the current in that winding. However, the capacitor and starting winding are not designed to carry that current continuously. The capacitor is disconnected by a centrifugal switch or some other means when the motor approaches the full operating speed. Thank You
